  • Flow diagram
  • Specifications
  • Ordering information
FSUSmart series
Medium Ultrapure Water System

-Ultrapure water, RO1st water

System overview
Breakthrough design to highlight the aesthetics of science and technology.

FS series, using the innovative automatic control system and LCD display, embedding new purification cartridges with patented structure, stable and reliable RO system with higher ion rejection rate, and DI ion-exchange cartridges with larger capacity, equipping with built-in 7.5-liter pressure water tank, more economical and cost-effective, is the economic choice for lab pure water.

System output ranges from 50 to 250 liters/h. It can simultaneously produce ultrapure water (18.2MΩ.cm), high pure water (>17.5MΩ.cm) or pure water(<5μs/cm) [1]. The quality of pure water fully meets or exceeds the requirements of water quality standard, specified by ASTM D1193-06, GB/T 11446.1-2013, GB/T 33087-2016, GB/T 6682-2008, CP, EP, USP, JP, CAP, CLSI, etc.
[1]. FSU/FSD series products can produce single RO water (ion rejection rate≥98%). FSRS series products can produce double RO water (<5μs/cm).
Application Area:
  • HPLC、UPLC、LC-MS
  • ICP-MS、ICP-AES、AAS、GC-MS
  • MALDI-TOF-MS、IC、TOC analysis
  • Electrochemical, spectrophotometric determination
  • Preparation of microbial media and reagents
  • Cell culture, PCR, IVF
  • Protein purification, electrophoresis, biochemistry
  • Proteomics, genomics, immunoassay
  • Feed water of laboratory instruments, such as: autoclave,
    bottle washing machine, environmental test chamber, water bath, etc.
    • Product Film
    Control System

    Smart Control System Bringing Efficiency & Convenience

    • White LCD display, size up to 68*87mm, shows intuitive and easy-to-read running status.
    • Real-time running status display of flushing, producing water, water full, water shortage and maintenance.
    • 2 water quality sensors (RO water, DI water or UP water) can monitor water quality and alarm real-timely.
    • 4 (PP/PC/RO/DI) consumables life management function, can real-timely display remaining life of consumables, automatically remind expiration replacement, and avoid water quality declines.
    • Acrylic touch panel, with 3-button layout, achieving fast system setup, RO forced flushing and easy 2-way water dispensing function, brings efficient and convenient operating experience.
    System Configuration

    Powerful 20-inch pretreated cartridge

    • PP cartridge with deep folding membrane, accuracy of 5μm, to filter particles efficiently in source water.
      • PC cartridge with high performance activated carbon fiber with catalyst, accuracy of 5μm, to adsorb organics and residual chlorine efficiently and avoid carbon powder precipitation maximumly.
        • The combination of folding filter & carbon fiber filter can bring greater cartridge processing capacity, extend the replacement cycle and reduce the running cost.

          Rigorous double RO system[1]

          • The automatic discharge function of unqualified RO water can ensure that the RO water quality is suitable to enter the back-end module.
            • Integral package of discarded RO module, easy to install and maintain.
              • Auto-flushing function of RO module, to effectively prevent scale and prolong the life of the membrane.
                • Double RO system can remove up to 99% soluble inorganic ions, 99% soluble organics, microorganisms and particles.
                  • Compared with single RO system, the double RO water quality can be stable < 5μs/cm (feed water conductivity < 1500μs/cm), and the life of the ultrapure unit is longer.
                    • Equipped with high quality RO membrane, to achieve combination of long life, stability and high ion rejection rate.
                      • [1]. Applicable to FSRS.

                      High performance purification cartridge

                      • Patented cartridge structure can prevent the stratification of resin and ensure the exchange capacity of cartridge.
                        • The resin filling capacity per cartridge is up to 5.2 liters, and up to 2 cartridges[1] can be equipped every host, with a total filling capacity of 10.4 liters, achieving greater ion exchange capacity and significantly reducing the running cost.
                          • All DuPont resin and high purity material of column ensure absolute 18.2MΩ.cm of ultrapure water resistivity and reduce TOC precipitation.
                            • [1].Applicable to products, whose output ≥150 l/h.

                            Built-in 7.5-liter pressure water tank

                            • With dual functions of water storage and pressurization, FDA approved, its fully enclosed structure effectively isolates air, and prevent the touching of CO2 and other pollutants with pure water. Up to 100 liters is optional volume.
                              • 100 liters PE pure water tank with liquid level sensor, equipped with air filter, is optional to achieve more professional pure water storage.

                                Double wavelength UV module[1]

                                • Long-life ultraviolet lamp (185&254nm), combined with SUS316L flow shell, can reduce the value of TOC to ≤2ppb[2], and can achieve efficient sterilization and inhibit bacterial growth, suitable for HPLC, UPLC, LC-MS and other precision instruments.
                                  • [1].Applicable to ultrapure water systems equipped with UV module.
                                  • [2].The values vary depending on the nature and concentration of contaminants in source water.

                                  Ultrafiltration module[1]

                                  • With PES membrane and MWCO>5000D, effectively removes pyrogen/endotoxin, RNase, DNase, and produces nuclease-free, proteinase-free and bacterial-free ultrapure water, suitable for life science applications, such as cell culture/IVF.
                                    • [1].Applicable to ultrapure water systems equipped with UF module.

                                    MF terminal microfilter[1]

                                    • (0.45+0.2)μm double-layer PES membrane, ensures microbial retention, effectively removes particles and bacteria, and meets critical application requirements.
                                      • [1].Applicable to ultrapure or high-pure water system. For details, refer to the product manual.

                                      UF terminal ultrafilter[1]

                                      • With PES membrane and MWCO>15000D, effectively removes pyrogen/endotoxin, RNase, DNase, and produces nuclease-free, proteinase-free and bacterial-free ultrapure water, suitable for life science applications, such as cell culture/IVF.
                                        • [1].Optional accessory for ultrapure water system only.
                                        Product overview
                                        FSU
                                        With tap water inlet, using the innovative automatic control system and LCD display, embedding new purification cartridges with patented structure, stable and reliable single RO system with higher ion rejection rate, and DI ion-exchange cartridges with larger capacity, equipping with built-in 7.5-liter pressure water tank.

                                        System output: 60, 120, 180, 250 liters/h. It can simultaneously produce ultrapure water (18.2MΩ.cm) and single RO water. The quality of pure water fully meets or exceeds the requirements of water quality standard specified by ASTM D1193-06, GB/T 11446.1-2013, GB/T 33087-2016, GB/T 6682-2008, CP, EP, USP, JP, CAP, CLSI, etc.
                                        Name Standard Low TOC Eliminating endotoxin Synthesizing
                                        Model FSU-60/120/180/250 FSU-60/120/180/250UV FSU-60/120/180/250UF FSU-60/120/180/250UVF
                                        Production rate[1] 60 series: 60 L/hour, 120 series: 120 L/hour, 180 series: 180 L/hour，250 series: 250 L/hour
                                        Dispensing rate[2] Up to 4.2 liters/minute Up to 4.2 liters/minute Up to 4.2 liters/minute Up to 4.2 liters/minute
                                        Ultrapure water quality[3]
                                        Resistivity (25℃)[4] 18.2 MΩ.cm 18.2 MΩ.cm 18.2 MΩ.cm 18.2 MΩ.cm
                                        Conductivity (25℃) 0.055 μs/cm 0.055 μs/cm 0.055 μs/cm 0.055 μs/cm
                                        TOC[5] 10 ppb[6] 3 ppb[7] 10 ppb[6] 3 ppb[7]
                                        Particles [8] <1 /ml (>0.2μm) <1 /ml (>0.2μm) <1 /ml (>0.2μm) <1 /ml (>0.2μm)
                                        Bacteria [9] <0.01 CFU/ml <0.01 CFU/ml <0.01 CFU/ml <0.01 CFU/ml
                                        Endotoxin [10] N/A N/A <0.001 EU/ml <0.001 EU/ml
                                        RNases [10] N/A N/A 1 pg/ml 1 pg/ml
                                        DNases [10] N/A N/A 5 pg/ml 5 pg/ml
                                        Protease[10] N/A N/A 0.15 μg/ml 0.15 μg/ml
                                        RO1st water quality[3]
                                        Ion rejection rate 98%-99%(with new RO module) 98%-99%(with new RO module) 98%-99%(with new RO module) 98%-99%(with new RO module)
                                        Organic rejection rate >99%(MW>300 Dalton) >99%(MW>300 Dalton) >99%(MW>300 Dalton) >99%(MW>300 Dalton)
                                        Particles and bacteria rejection rate >99% >99% >99% >99%
                                        Feed water requirements
                                        Water source type Tap water Tap water Tap water Tap water
                                        Pressure 2-6 bar 2-6 bar 2-6 bar 2-6 bar
                                        Temperature 5-40 ℃ 5-40 ℃ 5-40 ℃ 5-40 ℃
                                        Conductivity <2000 μs/cm <2000 μs/cm <2000 μs/cm <2000 μs/cm
                                        Total hardness(In CaCO3) <300 ppm <300 ppm <300 ppm <300 ppm
                                        TOC <2000 ppb <2000 ppb <2000 ppb <2000 ppb
                                        Free chlorine <3 ppm <3 ppm <3 ppm <3 ppm
                                        PH 4-10 4-10 4-10 4-10
                                        Dissolved CO2 <40 ppm <40 ppm <40 ppm <40 ppm

                                        Power supply 220V，50/60Hz 220V，50/60Hz 220V，50/60Hz 220V，50/60Hz
                                        Total Power 20 series: 48W, 40 series: 72W, 60 series: 120W
                                        Dimension (L×W×H) 450×521×1016mm 450×521×1016mm 450×521×1016mm 450×521×1016mm
                                        Weight About 58KG About 58KG About 58KG About 58KG
                                        Standard configuration Main host 1 set
                                        All cartridges 1 set
                                        7.5-liter pressure water tank 1 set                                        		 Main host 1 set
                                        All cartridges 1 set
                                        7.5-liter pressure water tank 1 set                                        		 Main host 1 set
                                        All cartridges 1 set
                                        7.5-liter pressure water tank 1 set                                        		 Main host 1 set
                                        All cartridges 1 set
                                        7.5-liter pressure water tank 1 set
                                        [1].Affected by inlet water quality, pressure, temperature and status of RO membrane [2].Affected by the tank status and terminal filter
                                        [3].The following values are typical and may vary depending on the nature and concentration of feed water contaminants [4]. According to USP requirements, the resistivity can be displayed as a non-temperature-compensated value
                                        [5].Affected by the type of organics [6].Inlet TOC<1000ppb, follow professional operating procedures and correct sampling conditions
                                        [7].Inlet TOC<50ppb, follow professional operating procedures and correct sampling conditions [8].Equip with terminal microfilter and follow professional operating procedures and correct sampling conditions
                                        [9].Equip with terminal microfilter and follow professional operating procedures and correct sampling conditions [10].Equip with terminal microfilter and follow professional operating procedures and correct sampling conditions
                                        Ordering information
                                        Item No Product description
                                        FSU-60 Medium ultrapure water system,60L/h, Standard, Ultrapure water, RO1st water
                                        FSU-120 Medium ultrapure water system,120L/h, Standard, Ultrapure water, RO1st water
                                        FSU-180 Medium ultrapure water system,180L/h, Standard, Ultrapure water, RO1st water
                                        FSU-250 Medium ultrapure water system,250L/h, Standard, Ultrapure water, RO1st water
                                        FSU-60UV Medium ultrapure water system,60L/h, Low TOC, Ultrapure water, RO1st water
                                        FSU-120UV Medium ultrapure water system,120L/h, Low TOC, Ultrapure water, RO1st water
                                        FSU-180UV Medium ultrapure water system,180L/h, Low TOC, Ultrapure water, RO1st water
                                        FSU-250UV Medium ultrapure water system,250L/h, Low TOC, Ultrapure water, RO1st water
                                        FSU-60UF Medium ultrapure water system,60L/h, Eliminating endotoxin, Ultrapure water, RO1st water
                                        FSU-120UF Medium ultrapure water system,120L/h, Eliminating endotoxin, Ultrapure water, RO1st water
                                        FSU-180UF Medium ultrapure water system,180L/h, Eliminating endotoxin, Ultrapure water, RO1st water
                                        FSU-250UF Medium ultrapure water system,250L/h, Eliminating endotoxin, Ultrapure water, RO1st water
                                        FSU-60UVF Medium ultrapure water system,60L/h, Synthesizing, Ultrapure water, RO1st water
                                        FSU-120UVF Medium ultrapure water system,120L/h, Synthesizing, Ultrapure water, RO1st water
                                        FSU-180UVF Medium ultrapure water system,180L/h, Synthesizing, Ultrapure water, RO1st water
                                        FSU-250UVF Medium ultrapure water system,250L/h, Synthesizing, Ultrapure water, RO1st water
                                        FSD-60 Medium pure water system,60L/h, Standard, High pure water, RO1st water
                                        FSD-120 Medium pure water system,120L/h, Standard, High pure water, RO1st water
                                        FSD-180 Medium pure water system,180L/h, Standard, High pure water, RO1st water
                                        FSD-250 Medium pure water system,250L/h, Standard, High pure water, RO1st water
                                        FSD-60UT Medium pure water system,60L/h, Eliminating bacteria and particle, High pure water, RO1st water
                                        FSD-120UT Medium pure water system,120L/h, Eliminating bacteria and particle, High pure water, RO1st water
                                        FSD-180UT Medium pure water system,180L/h, Eliminating bacteria and particle, High pure water, RO1st water
                                        FSD-250UT Medium pure water system,250L/h, Eliminating bacteria and particle, High pure water, RO1st water
                                        FSRS-50 Medium double RO water system,50L/h, Standard, RO2nd water, RO1st water
                                        FSRS-100 Medium double RO water system,100L/h, Standard, RO2nd water, RO1st water
                                        FSRS-150 Medium double RO water system,150L/h, Standard, RO2nd water, RO1st water
                                        FSRS-50UT Medium double RO water system,50L/h, Eliminating bacteria and particle, RO2nd water, RO1st water
                                        FSRS-100UT Medium double RO water system,100L/h, Eliminating bacteria and particle, RO2nd water, RO1st water
                                        FSRS-150UT Medium double RO water system,150L/h, Eliminating bacteria and particle, RO2nd water, RO1st water
                                        Item No Product description Item No Product description
                                        HPC104 Pretreatment cartridge D HPC603 UP cartridge, standard
                                        HPC366 RO1st module S660 HPC604 UP cartridge, Low TOC
                                        HPC393 RO1st module S912 HPC605 UP cartridge, standard
                                        HPC399 RO1st module S918 HPC606 UP cartridge, Low TOC
                                        HPC397 RO1st module S925 HPC710 Air filter for tank
                                        HPC395 RO1st module F905 HPC703 185&254nm double wavelength UV lamp
                                        HPC391 RO1st module F910 HPC704 254nm UV lamp
                                        HPC396 RO1st module F915 HPC709 UF ultrafiltration module
                                        HPC465 RO2nd module D650 HPC801 TF terminal microfilter
                                        HPC491 RO2nd module D910 HPC802 TF terminal microfilter
                                        HPC496 RO2nd module D915 HPC803 TF terminal microfilter
                                        HPC502 DI cartridge HPC804 TF terminal microfilter
                                        HPC503 DI cartridge HPC810 UF terminal ultrafilter
                                        Item No Product description Item No Product description
                                        DISP2001 HiDis dispenser arm (independent), equipped with 2M connection kit PWA7502 External leak sensor
                                        PWA7201 Automatic water softener (salt required) PWSL1000 Pure water suppling module (BA)
                                        PWA7020 Pretreatment filter for source water PWSL2000 Pure water storage and suppling module (PR)
                                        PWA7021 PP cartridge for pretreatment filter PWSM0500 Pure water storage and suppling module (FC-500L)
                                        PWA7022 RS cartridge for pretreatment filter PWSM1000 Pure water storage and suppling module (FC-1000L)
                                        PWA7501 Foot switch PWSM2000 Pure water storage and suppling module (FC-2000L)
                                        Item No Product description
                                        HPS51001 1 year extended warranty service (except for consumables)
                                        HPS51003 3 year extended warranty service (except for consumables)
                                        HPS52001 Verification documents in English
                                        HPS59001* 1-year, one-price all-inclusive maintenance agreement, including regular consumables replacement, maintenance and calibration
                                        HPS59003* 3-year, one-price all-inclusive maintenance agreement, including regular consumables replacement, maintenance and calibration
                                        HPS53001 Basic verification service
